RELATION OF BENDING DEFLECTION AND LATE DIMENTION (WITH REINFOR CING RIB) 1000MM WIDTH OF ALUMINUM PLASTIC COMPOSITE PANEL

Wind loading (Pa)

Allowable Plate length (mm)

Center Deflection (mm)

Spacing of rivet (mm)

500

8000

26

500

600

8000

32

500

700

8000

37

500

800

3700

37

500

900

3300

35

500

1000

3000

34

500

1100

2700

33

500

1200

2400

31

500

1400

2100

30

500

1600

1700

25

500

1800

1400

22

500

2000

1200

20

500

2200

1100

18

500

2400

1000

17

500

2600

900

16

500

2800

800

15

400

3000

750

15

400

RELATION OF BENDING DEFLECTION AND LATE DIMENTION (WITH REINFORCING RIB) 1250MM WIDTH OF ALUMINUM PLASTIC COMPOSITE PANEL

Wind loading (Pa)

Allowable Plate length (mm)

Center Deflection (mm)

Spacing of rivet (mm)

500

3800

35

500

600

3300

38

500

700

3000

38

500

800

2800

37

500

900

2500

36

500

1000

2300

35

500

1100

2000

31

500



Wind loading (Pa)

Allowable Plate length (mm)

Center Deflection (mm)

Spacing of rivet (mm)

1600

1300

23

500

1800

1100

21

500

2000

1000

20

500

2200

900

19

500

2400

800

18

400

2600

750

18

400

2800

700

17

400

3000

650

16

400

RELATION OF BENDING DEFLECTION AND LATE DIMENTION (WITH REINFORCING RIB) 1500MM WIDTH OF ALUMINUM PLASTIC COMPOSITE PANEL

Wind loading (Pa)

Allowable Plate length (mm)

Center Deflection (mm)

Spacing of rivet (mm)

500

3400

43

500

600

3000

42

500

700

2700

41

500

800

2300

36

500

900

2000

32

500

1000

1800

30

500

1100

1600

28

500

1200

1500

27

500

1400

1250

25

500

1600

1100

24

500

1800

1000

23

500

2000

900

22

400

2200

800

21

400

2400

750

20

300

2600

700

19

300

2800

350

18

300

3000

600

15

300

MACHINES USED IN FABRIC ACP

Aluminum Panel Automatic Cutting Machine

Aluminum Panel Automatic Cutting Machine

Aluminum Panel Cutting and Grooving Machine

Aluminum Panel Cutting & Grooving Machine

Aluminum Panel Revolving Machine
Aluminum Panel Revolving Machine
Handy Circular Saw Machine
Handy Circular Saw Machine

Processing Reference

Shearing
Shearing
Bending
Bending
Grooving
Grooving
Welding
Welding
Gluing
Gluing
Sawing
Sawing

Curve ruler ( Curve ruler with handgrip. soft protective mattress shall be arranged on the contact face with aluminum – plastic composite panel to prevent scuffing aluminum plastic panel while acting bending force) .

Representative grooving modes - Cushion Block
Secondly bending with right-angle convex shape
Bending with right angle suck - Cushion Block
In the hemming construct ion of aluminum-plastic composite panel, the hemmed position shall be grooved in accordance with the hemming requirement the grooving mode like V-groove and U-groove are common ly used (Figure E.0.1) .The special groover for aluminum-plastic composite panel shall be adopted, to ensure the grooving depth not damaging the opposite aluminum product, and reserving plastic layer (0.30mm in thickness) . Reinforcement measure may be adopted on the groov ing posit ion as required.
Representative grooving modes

INSTALLATION PROCESS

Screw Fastening
Screw Fastening
Fitting Part Suspending Fastening
Fitting Part Suspending Fastening
Fastener Fastening
Fastener Fastening
Layer Scres Fastening
Layer Scres Fastening
Suspending
Suspending
Suspending Fastening
Suspending Fastening
WELLBOND-panel
WELLBOND panel

1-WELLBONO Panel

2- Aluminum River

3- Aluminum Angle

4- Angle Bar

5- Gasket

6- Screw

7- Spacer

INSTALLATION METHODS

1
Securing Frame For Aluminum Window





1- WELLBOND Sheet

2- Gap Filler

3- Securing Frame For Aluminum Window

4- Framework

5- Insulating Materials

2
Self Taping Screw

1- WELLBOND Sheet

2- Gap Filler (Backing Rod + Silicon )

3- T-Shaped Aluminum

4- Self Taping Screw

5- Iron Angle

6- Aluminum Fitting

3
Securing Frame For Aluminum Window

1- WELLBOND Sheet

2- Gap Filler (Backing Rod + Silicon )

3- Securing Frame For Aluminum Window

4- Framework

5- Insulating Materials

4
Steel Framework

1- WELLBOND Sheet

2- Steel Framework

3- Aluminum Angle

4- Steel Framework

5
Insulating Materials

1- WELLBOND Sheet

2- Camber Line

3- Gap Filler ( Backing Rod + Silicon )

4- Self Taping Screw

5- Water Board

6- Framework

7- Insulating Materials

6
Backing Rod + Silicon

1- WELLBOND Sheet

2- Gap Filler (Backing Rod + Silicon )

7
Gap Filler (Backing Rod + Silicon )

1- WELLBOND Sheet

2- Aluminum Fitting

3- Gap Filler (Backing Rod + Silicon )

4- Framework

5- Insulating Materials



8
Framework

1- WELLBOND Sheet

2- Gap Filler (Backing Rod + Silicon )

3- Framework

4- Insulating Materials

9
Supporting Frame

1- WELLBOND Sheet

2- Gap Filler

3- Break water

4- Insulating Materials

5- Supporting Frame

10
Insulating Materials

1- WELLBOND Sheet

2- Gap Filler (Backing Rod + Silicon )

3- Insulating Materials

4- Framework

11
Cement Post Construction Method

Cement Post Construction Method

1- WELLBOND Sheet

2- Gap Filler (Backing Rod + Silicon )

3- Support

Supporting Frame Constructing Method

Supporting Frame Constructing Method

1- WELLBOND Sheet

2- Framework

3- Break Water

4- Insulating Material

Common Constructing Method

Common Constructing Method

1- WELLBOND Sheet

2- Iron Angle

3- Break Water

4- Adjustable Framework
